ArmorWall™ Plus FR SIS

<p>5-in-1 Composite Panel for Commercial Wall Systems</p>

Image 1
image 3
im1g2
image alt Play icon
image alt
imag2 5

ArmorWall™ Plus FR SIS

<p>5-in-1 Composite Panel for Commercial Wall Systems</p>

<p>Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. In fermentum posuere urna nec tincidunt.</p> <ul> <li>DuPont™ ArmorWall™ Plus Fire-Rated Structural Insulated Sheathing  (SIS) </li> <li>DuPont™ ArmorWall™ SP Plus Fire-Rated Structural Insulated Sheathing (SIS) available with ArmorSeal System as part of a complete  system</li> </ul> <p></p> <p>Ultricies mi eget mauris pharetra et ultrices neque ornare aenean. Habitant morbi tristique senectus et netus et.</p>




Resources




Product Information Sheets Installation Guides Guide Specifications Assembly Details Substitution Package Technical Documents Brochure Codes & Certifications Warranty




Features & Benefits





Continuous Installation
  • High performance, poured polyurethane insulation • layer fused to the sheathing layer with patented
  • Fusion Technology
  • Complies with continuous insulation requirements in building codes
  • Available in 3-thicknesses and 3-R-Values to fit your application
View More
Fire Resistance
  • Passes NFPA 285 Testing with the additive protection of an exterior cladding on the front
  • When used with DuPont ArmorWall Systems as part of  a complete wall assembly, allows for engineering judgments to be made for most NFPA 285 testing
dfd dffff
Water-Resistive Barrier
  • Passes ASTM E331 once sheathing has been properly sealed
View More
Structural Sheathing & Cladding Support
  • Tested to support loads equivalent to most building cladding finishes, with minimal creep under load.
  • Uses Magnesium Oxide MgO sheathing to add high strength
Alt image
Air-Resistive Barrier

Once sheathing fasteners and seams are properly sealed, meets the IBC and ASTM E283 requirements, without the need for additional materials

Cladding Attachment Support

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. In fermentum posuere urna nec tincidunt. Ultricies mi eget mauris pharetra et ultrices neque ornare aenean. Habitant morbi tristique senectus et netus et.





Specifications





Physical Properties

  Method Unit Value
Air Leakage Resistance<sup></sup> ASTM E2357 - Pass
Air Infiltration at 75 Pa<sup></sup> ASTM E283 - 0.01 cfm/ft2 (0.1 L/s/m2)
Air Infiltration at 300 Pa<sup></sup> ASTM E283 - 0.04 cfm/ft2 (0.2L/s/m2)
Water Penetration at 6.27 psf (300 Pa)<sup>1</sup> ASTM 331 - Pass
Mold and Mildew<sup></sup> ASTM C1338 - Pass
Fastener Sealability<sup>2</sup> ASTM D1970 - Pass
Fire Resistance<sup>3</sup> NFPA 285 - Pass
Vapor Permeance (entire assembly)<sup></sup> ASTM E96, Procedure A - 0.5 Perms (grains/hr in Hg ft2)
Flame Spread/Smoke Developed Index (facer)<sup></sup> ASTM E84 - 0 / 0
Flame Spread/Smoke Developed Index (insulation)<sup></sup> ASTM E84 - 10 / 250
Thermal Resistance<sup></sup> ASTM C518 (ASTM-54) per inch 6.5
Foam Compression<sup></sup> ASTM D1621 (ASTM-65) psi 30
Fastener Withdrawal Capacity<sup>4</sup> ASTM D17614,5 - 284 lbs
Fastener Pull Through<sup>5</sup> ASTM D17614,5 - 505.2 lbs
Fastener Shear in Sheathing Only<sup></sup> ASTM D17614,5 - 519 lbs

1Total test duration two continuous hours.

2ArmorWall™ SP Plus FR SIS is self-sealing around cladding attachment fasteners

3ArmorWall™ SP Plus FR SIS passes NFPA 285 attached directly to the stud framing allowing most cladding installed to its exterior as inclusive to the NFPA 285 approved assembly.

4Average ultimate value after thermal cycling (10 cycles) provided

5Fastener data reflects attachment to the panel not attachment to structure.





Available Sizes

Thickness Width Length R-Value
3.75 48 96 R17
2.75 48 96 R11
4.25 48 96 R21



✕
